Specifications
(50／60Hz)
| Mounting type | Side-mounting |
|---|---|
| Cooling capacity(W) | 2600 |
| Setting Temperature Range(℃) | 25～45 |
| Use Area Temperature(℃) | 20～55 |
| Use Area Humidity(%RH) | 10～85 (No condensation) |
| External dimensions(mm) | H1000×W450×D260 |
| Weight(kg) | Approx. 44 |
| Coating Color | Equivalent color of light beige 5Y 7/1 |
| Rated Voltage(V) | Single-phase AC200～240 |
| Consumption Current: Rated(A) | 6.9 |
| Consumption wattage: Rated(W) | 1180 |
| Recommended breaker capacity (A) | 15 |
| Vibration Resistance | JIS Z0200 Level1 |
| Dust prevention / dust proof protection class | Equivalent to IP54 (internal circulation route) |
| Refrigerant / Fill ration(g) | R1234yf 840g |
| Noise (dB (A)) | Approx. 76 |
| External Output | Rated voltage normally open : 250 VAC 2A／30 VDC 2A |
| Display | Internal temperature／Error／RUN |
Cooling Capacity : Rated capacity value when external temperature is 35°C and humidity is 40%RH , internal temperature is 35°C and humidity is 40%RH, power source & voltage : 200V.
(Test method: JIS B 8615-1 Indoor air enthalpy test method)
Use area temperature / humidity : Use area temperature / humi dity is not meant to satisfy all conditions in temperature and humidity.
Dust prevention / dust proof protection class : Excluding dra in pipe section
Reading an instruction manual well certainly before use and p lease use it right.
External dimensions
Diagram of Panel Cutout
