Home Test and Measurements 2600B Series SMU
MD series
Back to products
Placeholder
2601B-PULSE 10 µsec Pulser/SMU
Click to enlarge
Keithley

2600B Series SMU

Brand

Keithley

Sub Categories

Electric & Electronic Test and Measurements

Application

Source Measure Units

Category: Test and Measurements
Share:
close
YOU MAY ALSO LIKE…
  • AD-4991 Series X-ray Inspection Systems
  • AD-4971 Series Metal Detectors
  • AD-4976 Series Metal Detectors
  • Heavy Duty Checkweigher AD-4943B
  • Description
Description

Keithley’s Series 2600B System SMU instruments are the industry standard current-voltage source and measure solution for highly automated production test applications. Both dual- and single-channel models tightly integrate a precision power supply, true current source, DMM, and electronic load with pulse generating capabilities. Plus, TSP® technology runs complete test programs for automated system applications, and TSP-Link® technology enables daisy-chaining up to 64 channels for high volume parallel test.

CHANNELS MIN V/I PULSE SOURCE V/I RANGE MAX SPEED
2 or 1 <100 µs
0.1% settled
0.1 fA to 10 A,
100 nV to 200 V
20k readings/s to buffer



Complete production test without sacrificing footprint

Meet all your production test needs with two completely isolated channels of wide dynamic source and measure within the same footprint. Each 40 W channel provides 6½-digit precision resolution source and measure from 10 A pulse to 0.1 fA and 200 V to 100 nV at less than 100 µs pulse width and within 0.1% of settled value.

Highlights

  • Up to 2 channels in the same footprint
  • Widest dynamic range of voltage and current
  • Highly accurate 100 µs pulse expanding DC production test capabilities
ACS Laptop Setup

Embedded scripting for unmatched production throughput

Meet all your production test needs with two completely isolated channels of wide dynamic source and measure within the same footprint. Each 40 W channel provides 6½-digit precision resolution source and measure from 10 A pulse to 0.1 fA and 200 V to 100 nV at less than 100 µs pulse width and within 0.1% of settled value.

Highlights

  • Eliminates time-consuming bus communications to and from the PC
  • Advanced data processing and flow control
  • Versatile prober/handler control
Embedded-Scripting

System performance, without a mainframe

TSP-Link® technology enables expansion up to 64 channels for high-speed, SMU-per-pin parallel testing without a mainframe. All channels are simultaneously and independently controlled at a tight <500 ns.

Highlights

  • Supports <500 ns channel-to-channel synchronization
  • Up to 32 SMUs or 64 independent SMU channels
  • Reconfigure easily as test requirements change

Best low current performance for production

The 2635B and 2636B SMUs provide 0.1 fA, 10-16 resolution on the lowest 100 pA range, reducing ultra-low level sample characterization worries and assuring production success.

Highlights

  • 7x faster settling time on the lowest current range
  • Best low current resolution on the market
  • Direct triax connection simplifies setup
2600B_Settling

Learn more. Gain more.

Source Measure Unit Tutorial Learning Center brings together a wealth of information on Keithley SMUs and other products in an all-in-one, convenient location. We provide links to a wide variety of content related to the applications and industries we serve.

four key SMU tests
Model Channels Max Current Source/Measure Range Max Voltage Source/Measure Range Measurement Resolution (Current / Voltage) Power
2601B 1 10A 40V 100fA / 100nV 200 W
2611B 1 10A 200V 100fA / 100nV 200 W
2604B 2 10A 40V 100fA / 100nV 200 W
2614B 2 10A 200V 100fA / 100nV 200 W
2602B 2 10A 40V 100fA / 100nV 200 W
2612B 2 10A 200V 100fA / 100nV 200 W
2635B 1 10A 200V 0.1fA / 100nV 200 W
2634B 2 10A 200V 1fA / 100nV 200 W
2636B 2 10A 200V 0.1fA / 100nV 200 W
